FLEXO® NX - Nomex® Fabric Braided Sleeving Provides Extra Protection From Flames & Intense Heat
Soft, Pliable Flame Protection to 350 °C
- Soft and flexible flame protection
- Easy to cut with scissors
- Pressure resistance up to 6,200 bar
- Permanent temperature range: -60°C to 220°C, melting point 350°C
Flexo NX will protect your application in temperatures up to 350 °C. It is unaffected by short term exposure to most acids, bases, solvents and common engineering chemicals. Despite the soft touch and smooth appearance associated with woven aramid fibers, Flexo& NX is incredibly strong, with a tensile strength of 90,000 psi.
The densely braided sleeving provides full coverage and protection on even the most exposed applications.
Flexo NX sleeving cuts easily with regular scissors and the smooth surface eases installation even over long wire runs.
Nomex® is a registered trademark of the DuPont Corporation.
Certifications
|
Artikel-
nummer
|
Durchmesser
Innen in mm
|
Expansion
min. / max.
|
Mini
Spool
|
Bulk
Spool
|
|---|---|---|---|---|
|
NXN0.13
|
3,2 mm
|
1,6 - 6,4 mm
|
7,6 m
|
30,5 m
|
|
NXN0.25
|
6,4 mm
|
3,2 - 7,9 mm
|
7,6 m
|
30,5 m
|
|
NXN0.31
|
7,9 mm
|
5,6 - 11,1 mm
|
7,6 m
|
30,5 m
|
|
NXN0.38
|
9,5 mm
|
6,4 - 12,7 mm
|
7,6 m
|
30,5 m
|
|
NXN0.50
|
12,7 mm
|
7,9 - 15,9 mm
|
7,6 m
|
30,5 m
|
|
NXN0.63
|
15,9 mm
|
11,1 - 22,2 mm
|
7,6 m
|
30,5 m
|
|
NXN0.75
|
19,1 mm
|
12,7 - 19,1 mm
|
7,6 m
|
30,5 m
|
|
NXN1.00
|
25,4 mm
|
19,1 - 28,6 mm
|
7,6 m
|
30,5 m
|
|
NXN1.25
|
31,8 mm
|
25,4 - 38,1 mm
|
7,6 m
|
30,5 m
|
|
NXN1.50
|
38,1 mm
|
31,8 - 44,5 mm
|
7,6 m
|
30,5 m
|
|
NXN1.75
|
44,5 mm
|
38,1 - 50,8 mm
|
7,6 m
|
30,5 m
|
