FLEXO® OVEREXPANDED™ - Extreme Expandable Braided Sleeving for Cable Bundling
Extra Expansion for Easy Installation
- - Extreme stretchability
- Universal cable cladding with permeable fabric construction
- PET monofilament
- Permanent temperature range: -70°C to 125°C, melting point 250°C
Flexo Overexpanded has many uses where inexpensive bundling and management is the principal consideration.
Created to provide a fast and easy solution for automotive and marine wiring, Flexo Overexpanded expands to nearly 4 times its nominal diameter, easing installation over large plugs and connectors.
The open construction allows the underlying harness covering to show through for a unique and attractive assembly. The material cuts easily with a hot knife for a fray resistant end.
Certifications
|
Artikel-
nummer
|
Durchmesser
Innen in mm
|
Expansion
min. / max.
|
Mini
Spool
|
Bulk
Spool
|
|---|---|---|---|---|
|
PTO0.25
|
6,4 mm
|
3,2 - 12,7 mm
|
61,0 m
|
304,9 m
|
|
PTO0.38
|
9,5 mm
|
4,8 - 25,4 mm
|
38,1 m
|
152,4 m
|
|
PTO0.50
|
12,7 mm
|
11,1 - 34,9 mm
|
30,5 m
|
152,4 m
|
|
PTO0.75
|
19,1 mm
|
12,7 - 44,5 mm
|
22,9 m
|
76,2 m
|
