h2a050bk
SHRINKFLEX® 2:1 DUAL WALL ADHESIVE - Dual Wall Adhesive Lined Polyolefin Heatshrink
h2a050bk

SHRINKFLEX® 2:1 DUAL WALL ADHESIVE - Dual Wall Adhesive Lined Polyolefin Heatshrink

Product No.:
H2A0.50BK
From USA warehouse: Approx. 2 weeks From USA warehouse: Approx. 2 weeks (abroad may vary)
7,22 EUR
6,02 EUR per lfm

plus 19% tax excl. Shipping costs

Please enter the desired quantity.
Add to wish list
Ask about product
Description

Dual Wall Adhesive Lined Polyolefin Heatshrink Tubing

  • weatherproof, watertight and durable seal
  • Internal adhesive for sealing
  • Flame retardant
  • Permanent temperature range: -55°C to 125°C
Dual wall adhesive lined polyolefin heatshrink tubing is ideal for producing strong, weather tight seals on any heatshrink installation. During the application of heat from a heat gun or other hot air tool, the inner adhesive wall melts and flows, creating an adhesion layer to ensure a snug fit to your harness or connector.

Shrinkflex adhesive lined heatshrink tubing has a 2:1 shrink ratio and is available in 4 colors in 4' precut sticks.



Certifications


Zertifikat 1   Zertifikat 3   Zertifikat 4


Artikel-
nummer
Durchmesser
Innen in mm
Ø Innen
vor / nach


Länge
Stück

H2A0.13
3,2 mm
3,2 - 1,6 mm

1,2 m
H2A0.25
6,4 mm
6,4 - 3,2 mm

1,2 m
H2A0.38
9,5 mm
9,5 - 4,8 mm

1,2 m
H2A0.50
12,7 mm
12,7 - 6,4 mm

1,2 m
H2A0.75
19,1 mm
19,1 - 9,5 mm

1,2 m
H2A1.00
25,4 mm
25,4 - 12,7 mm

1,2 m
H2A1.50
38,1 mm
38,1 - 19,1 mm

1,2 m
Data sheet
You can download the appropriate data sheet here.
